Garmin GDL 82 User Manual

System Configuration
190-01810-00 GDL 82 TSO Installation Manual
Rev. 5 Page 7-10
7.3 Configuration
Configure the installation parameters on the System page after installation.
Figure 7-11 System Page
7.3.1 Aircraft
Configure the following:
Tail Number
Enter the aircraft tail number. If the aircraft has a U.S. registered tail number, select Compute ICAO to automatically
fill in the ICAO address.
ICAO Address
If not automatically computed, set the ICAO address as specified in the aircraft registration records.
Emitter Category
Select the aircraft type.
Table 7-1 Emitter Categories
Stall Speed
Set the stall speed for air/ground determination to the value of aircraft landing configuration stall speed (Vs0).
SELECTION DESCRIPTION
Light Light (ICAO) < 15,000 lbs maximum gross weight
Rotorcraft Rotorcraft
