Installation Planning and Considerations
190-01810-00 GDL 82 TSO Installation Manual
Rev. 5 Page 4-5
4.4.2 GPS Antenna
Table 4-3 Acceptable GPS/SBAS Antennas
[1] Same mounting hole pattern as GA 56, but GA 35 antenna has a physically larger footprint.
[2] The GPS connector is a TNC type. The Very High Frequency (VHF) connector is a BNC type.
[3] The GPS connector is a TNC type. The XM connector is a TNC type. The VHF connector is a BNC type.
MANUFACTURER PART NUMBER
MODEL/
DESCRIPTION
CONNECTOR
TYPE
GARMIN
ORDER
NUMBER
Garmin 013-00235-( )
GA 35,GPS/WAAS
[1]
TNC 013-00235-( )
Aero Antenna AT575-93G( )-TNCF-000-RG-27-NM
Garmin 013-00244-( )
GA 36,GPS/WAAS TNC 013-00244-( )
Aero Antenna AT575-126G( )-TNCF-000-RG-27-NM
Garmin 013-00245-( )
GA 37,
GPS/WAAS/XM
TNC 013-00245-( )
Aero Antenna AT2300-126G( )-TNCF-000-RG-27-NM
Garmin 013-00261-( )
A33W, WAAS TNC 013-00261-( )
Aero Antenna AT575-332G( )- TNCF-000-RG-27-NM
Comant CI-2580-200 GPS/VHF TNC/BNC [2] N/A
Comant CI-2728-200 GPS/VHF TNC/BNC [2] N/A
Comant CI-2580-410 GPS/XM/VHF TNC/TNC/BNC [3] N/A
Comant CI-2728-410 GPS/XM/VHF TNC/TNC/BNC [3] N/A
Comant CI-428-200 GPS/WAAS TNC N/A
Comant CI-428-410 GPS/XM TNC/TNC N/A
