Garmin GPSMAP943XSV User Manual

GPSMAP 9x3 Specifications
Dimensions (W × H × D) 233.0 × 162.3 × 75.8mm (9
3
/
16
× 6
3
/
8
× 3in.)
Dimensions with cover on bail mount (W × H × D) 256.2 × 178.1 ×104.7mm (10
1
/
16
x 7 x 4
1
/
8
in.)
Clearance to next obstruction behind chartplotter 33.2mm (1
5
/
8
in.)
Display size (W × H)
198.7 × 111.8mm (7
13
/
16
× 4
3
/
8
in.)
22.9cm (9.0in.) diagonal
Display resolution WXGA, 1280 ×720 pixels
Weight 1.6kg (3.6lb.)
Compass-safe distance 30cm (11.81in.)
Max. power usage at 10Vdc
Non-sonar models: 22.0W
Sonar models: 40.2W
Typical current draw at 12Vdc
Non-sonar models: 1.34A
Sonar models: 1.37A
Max. current draw at 12Vdc
Non-sonar models: 1.78A
Sonar models: 3.20A
Temperature range From -15° to 55°C (from 5° to 131°F)
Material Polycarbonate plastic and die-cast aluminum
Water rating IEC 60529 IPX7
5
Input voltage From 10 to 32Vdc
Fuse 6A, 125V fast-acting
NMEA 2000 LEN @ 9Vdc 2
NMEA 2000 draw 75mA max.
Max. waypoints 5,000
Max. routes 100
Max. active track points 50,000 points, 50 saved tracks
Wireless frequency 2.4GHz @ 18.3dBm max.
Memory card 2 microSD card slots; 32GB max. card size
5
The device withstands incidental exposure to water of up to 1m for up to 30min. For more information, go to www.garmin.com/waterrating.
186 Appendix
