GPSMAP 12x3 Specifications
Dimensions (W × H × D) 308.3 × 227.6 × 81.8mm (12
1
/
8
× 8
15
/
16
× 3
1
/
4
in.)
Dimensions with cover on bail mount (W × H × D) 327.2 × 246.3 × 113.8mm (12
7
/
8
× 9
11
/
16
× 4
1
/
2
in.)
Clearance to next obstruction behind chartplotter 93.6mm (3
11
/
16
in.)
Display size (W × H)
262.1 × 164.2mm (10
15
/
16
× 6
7
/
16
in.)
30.7cm (12.1in.) diagonal
Display resolution WXGA, 1280 × 800 pixels
Weight 3.0kg (6.6lb.)
Compass-safe distance 45cm (17.72in.)
Max. power usage at 10Vdc
Non-sonar models: 26.5W
Sonar models: 43.0W
Typical current draw at 12Vdc
Non-sonar models: 1.67A
Sonar models: 1.68A
Max. current draw at 12Vdc
Non-sonar models: 2.15A
Sonar models: 3.56A
Temperature range From -15° to 55°C (from 5° to 131°F)
Material Polycarbonate plastic and die-cast aluminum
Water rating IEC 60529 IPX7
6
Input voltage From 10 to 32Vdc
Fuse 6A, 125V fast-acting
NMEA 2000 LEN @ 9Vdc 2
NMEA 2000 draw 75mA max.
Max. waypoints 5,000
Max. routes 100
Max. active track points 50,000 points, 50 saved tracks
Wireless frequency 2.4GHz @ 18.3dBm max.
Memory card 2 microSD card slots; 32GB max. card size
6
The device withstands incidental exposure to water of up to 1m for up to 30min. For more information, go to www.garmin.com/waterrating.
