Garmin GPSMAP943XSV User Manual

Sonar Models Specifications
Specification Measurement
Sonar frequencies
7
Traditional: 50/200, 77/200, 83/200kHz
Single Channel CHIRP: from 40 to 250kHz
Garmin ClearVü CHIRP: 260/455/800kHz
Ultra High-Definition Garmin ClearVü: 0.8Mhz (800kHz), CHIRP range: 760 to
880kHz
Ultra High-Definition SideVü: 1.2 MHz (1,200kHz), CHIRP range: 1,060 to 1,170kHz
Sonar transmit power
(RMS)
8
CHIRP: 1000W
Garmin ClearVü and SideVü CHIRP: 500W
Sonar depth
9
5,000ft. at 1kW
7
Dependent upon the transducer.
8
Dependent upon the transducer rating and depth.
9
Dependent upon the transducer, water salinity, bottom type, and other water conditions.
188 Appendix
