Recommended Startup Image Dimensions
For the best fit for the startup images, use an image that has the following dimensions, in pixels.
Display resolution Image width Image height
WVGA 680 200
WSVGA 880 270
WXGA 1080 350
HD 1240 450
WUXGA 1700 650
Creating a New Combination Page
You can create a custom combination page to suit your needs.
1 Select Combo > Add Combo.
2 Select a window.
3 Select a function for the window.
4 Repeat these steps for each window of the page.
5 Hold a window to rearrange it.
6 Hold a data field to select new data.
7 Select Layout, and select a layout.
8 Select Name, enter a name for the page, and select Done.
9 Select Overlays, and select which data to show.
10 Select Done when you have finished customizing the page.
12 Customizing the Chartplotter
