4–12 350 FEEDER PROTECTION SYSTEM – INSTRUCTION MANUAL
A3 RECORDS CHAPTER 4: ACTUAL VALUES
A3 Records
The 350 has an event recorder which runs continuously. All event records are stored in
memory such that information is maintained for up to 3 days even after losing relay
control power. The events are displayed from newest to oldest event. Each event has a
header message containing a summary of the event that occurred, and is assigned an
event number equal to the number of events that have occurred since the recorder was
cleared. The event number is incremented for each new event.
Event records
The Event Recorder runs continuously, capturing and storing the last 256 events. All events
are stored in non-volatile memory where the information is maintained, even in the case
where relay control power is lost.
Shown below is an example of an event record caused by a Breaker Open operation, and
the recorded information at the time of this record.
PATH: ACTUAL VALUES > A3 RECORDS > EVENT RECORDS
Table 4-1: Example of Event Record
A3 EVENT REC T:778 E778 Jan 30,2009
BKR Stat Open 16:30:23.324
â–¶ E778, CONTROL BKR Stat Open PHASE A
CURRENT: 0.0 A 0° Lag
â–¼
E778, CONTROL BKR Stat Open PHASE B
CURRENT: 0.0 A 0° Lag
â–¼
E778, CONTROL BKR Stat Open PHASE C
CURRENT: 0.0 A 0° Lag
â–¼
E778, CONTROL BKR Stat Open
GROUND CURRENT: 0.0 A 0° Lag
â–¼
E778, CONTROL BKR Stat Open NTRL
GND CURRENT: 0.0 A
â–¼
E778, CONTROL BKR Stat Open PHASE
A-B VOLTAGE 0 V 0°
â–¼
E778, CONTROL BKR Stat Open PHASE
B-C VOLTAGE 0 V 0°
â–¼
E778, CONTROL BKR Stat Open PHASE
C-A VOLTAGE 0 V 0°
â–¼
E778, CONTROL BKR Stat Open
FREQUENCY 0.00 Hz
â–¼
E778, CONTROL BKR Stat Open 3ph
REAL POWER 0.0 kW
â–¼
E778, CONTROL BKR Stat Open 3ph
REACTIVE POWER 0.0 kvar
â–¼
