CHAPTER 1: INTRODUCTION SPECIFICATIONS
350 FEEDER PROTECTION SYSTEM – INSTRUCTION MANUAL 1–23
APPROVALS
EAC
The EAC Technical Regulations (TR) for Machines and Equipment apply to the Customs
Union (CU) of the Russian Federation, Belarus, and Kazakhstan.
Physical
DIMENSIONS
NOTE:
Refer to Chapter 2 for details
NON-DRAWOUT UNIT
Height:...................................................................... 7.98” (202.7 mm)
Width: ....................................................................... 6.23” (158.2 mm)
Length:..................................................................... 9.35” (237.5 mm)
DRAWOUT UNIT
Height:...................................................................... 7.93” (201.51 mm)
Width: ....................................................................... 6.62” (138.2 mm)
Length:..................................................................... 9.62” (244.2 mm)
WEIGHT
NON-DRAWOUT UNIT
Weight (net): .......................................................... 2.9 kg (6.4 lbs)
Weight (gross):...................................................... 4.0 kg (8.6 lbs)
DRAWOUT UNIT
Weight (net): .......................................................... 3.9 kg (8.6 lbs)
Weight (gross):...................................................... 5.0 kg (11.0 lbs)
Applicable Council Directive According to:
Low voltage directive 2014/35/EU
CE compliance EMC Directive 2014/30/EU
UL 508
North America cULus UL 1053
C22.2. No 14
EAC Machines and Equipment TR CU 010/2011
Lloyd’s Register Rules and Regulations for the
Classifications of Ships
Marine Applications: ENV2, ENV3
IEC 61850 IEC 61850 Certificate Level B IEC 61850-10
ISO Manufactured under a registered
quality program
ISO9001
Item Description
Country of origin Spain or Canada; see label on the unit
Date of manufacture See label on the side of the unit
Declaration of Conformity and/or Certificate of
Conformity
Available upon request
