350 FEEDER PROTECTION SYSTEM – INSTRUCTION MANUAL 5–1
350 Feeder Protection System
Chapter 5: Quick setup - Front control
panel
GE
Grid Solutions
Quick setup - Front control panel
The “Quick Setup” utility is part of the 350 relay main menu, and can be used for quick and
easy programming. Power system parameters, and settings for some simple over-current
elements can be easily set.
NOTE:
Ensure the relay is in "Relay Ready" state before using Quick Setup.
Figure 5-1: Quick Setup menu
ACTUAL VALUES
COMMANDS
QUICK SETUP
SETPOINTS
MAINTENANCE
QUICK SETUP
RELAY STATUS
NOMINAL FREQUENCY
PH CT PRIMARY
PH CT SECONDARY*
[SENS] GND CT PRIMARY
[SENS] GND CT SECONDARY*
VT CONNECTION
VT SEC. VOLTAGE
VT RATIO
AUX VT SECONDARY
AUX VT RATIO
VT FUSE FAIL
PH TOC FUNCTION
[SENS] GND TOC FUNCTION
NTRL TOC FUNCTION
PH IOC1 FUNCTION
[SENS] GND IOC1 FUNCTION
ٕ
898788A6.cdr
* Present only for universal CT
To Next Page
