7KHGUXPKDVWKUHHUHSODFHDEOHEDႉHV

Drum Removal

1. Remove the dryer front panel. (See Dryer

Front Panel in this section of this service

guide.)

2. Remove the drive belt from the motor. (See

Drive Belt in this section of this service

guide.)

3. Pull the drum forward and guide it out of the

cabinet.

The drum shaft is attached to the rear of the

drum with three T-20 Torx-head screws. The

EHDULQJFDQEHUHPRYHGE\SXOOLQJLWRႇWKHVKDIW

7KHGUXPVKDIWDQGEHDULQJ¿WLQWRWKHEHDULQJ

retainer in the center of the heater assembly

HOHFWULFPRGHOVRUGLႇXVHUDVVHPEO\JDV

models).

To access the drum shaft and bearing, it is

necessary to remove the drum. (See Drum in

this section of this service guide.)

Drum Shaft

Bearing

Drum 'UXP6KDIWDQG%HDULQJ
