Any time the lid is in the down position, the lid

actuator presses down on lid lock mechanism.

When the washer goes into the spin or rinse

portion of a cycle, a lock routine will occur.

The control will send 120 VAC from J513 pin 1

to the lid lock heating the lock PTC. The lock

PTC will remain energized while the lid is locked.

This will close the bimetal switch completing the

circuit.

When the lid is closed, the lid lock engages the lid

actuator and prevents opening the lid during the

spin cycle and while the basket is spinning.

The lock will be released approximately 5

seconds after the basket stops spinning.

NOTE: If there is a power outage the lid lock can

take 3 minutes to release.

The lid lock is attached to the top cover assembly

with two Phillips-head screws. (See Top Cover

Assembly in the Washer Components section

of this service guide.) The lid must be open to

access the screws. The top cover assembly must

be raised approximately 4 inches to remove the

lid lock.

The lid lock is connected to the washer with a

wire harness.

Disconnect

Lid Lock

Lid Actuator

Lid Lock

(below

opening)

(Continued Next Page)

Lid Lock
