GE PACE6000 User Manual

PACE Pressure Controller User Manual
[EN] English 6 - 21 K0443 Revision A
Idle Timeout
Starts when the controller achieves the set-point after the
set time, if new set-points are not entered the timer will
time-out and return to measure mode.
Gas Head Correction
Corrects pressure output for the height difference
between instrument and UUT:
• For UUT positioned higher than the reference level of the PACE instrument enter a positive
height correction.
• For UUT positioned lower than the reference level of the PACE instrument enter a negative
height correction.
• When calibrating the PACE instrument disable the gas head correction and correct the
actual applied pressures for height.
Power Up
With Normal mode selected, the instrument powers up in Measure mode.
With regulator mode selected, the instrument powers-up in Control mode at a pre-selected
set-point value.
Note: When using regulator mode, disable the Idle Timeout feature.
Lock Tasks
Individual tasks
:
Allows any combination of individual tasks to be disabled.
Note: Restricts operation of the instrument to specific tasks or functions, use for production
procedures.
All
:
Disables all tasks.
Change PIN
Changes the Supervisor PIN: enter the existing PIN, then the new PIN and confirmation of the
new PIN.
Note: Confirmation of the new PIN permanently replaces the old PIN. Record this new PIN
and keep in a safe place. If new PIN is lost it can only be reset by returning the
instrument to a GE service centre.
User defined units
Permits the user to define a set of pressure conversion units. Following the on-screen
prompts special units may be set by selecting a Pascal multiplier and assigning a five
character name.
Instrument alias name
Permits the user to define a 20 character alias name for the instrument. The instrument
returns this name through the communications interfaces.
Reference
Level
