6 Reference and Specification
K0443 Revision A 6 - 30 [EN] English
Example Program
Note: Changes to instrument settings made in a test program remain valid only for the test
program.
The instrument reverts to the pre-test settings on completion.
Step Command Argument Action
START Program start
1
UNITS mbar Select units, mbar
2
RATE 100 Select rate, 100 mbar/min
3
IN LIMITS TIME 10 (00:00:10) secs
4
IN LIMITS Set In Limits Band
5
RESOLUTION 5 Display resolution, 5 digits
6
SETTLING No overshoot
7
TEXT Operator instruction, e.g.”Connect UUT”
8
ZERO
9
SET-POINT 400 Set-point, 400 mbar
10
CONTROL Controller ON
11
WAIT IN LIMITS Wait for In Limits Condition
12
BEEP Beep on, approx. 1 sec, Beep off
13
MEASURE Switch to Measure (controller off)
14
DWELL 30 Wait for 30 sec (00:00:30)
15
SET-POINT 800 Set-point, 800 mbar
16
CONTROL Controller on
17
WAIT IN LIMITS Wait for In Limits Condition
18
BEEP ON Beep on, approx. 1sec, Beep off
19
MEASURE Switch to Measure (controller off)
20
TEXT
Operator instruction, e.g. (Wait for beep, record pressure)
21
DWELL 30 Wait for 30 sec
22
BEEP Beep on, approx. 1 sec, Beep off
23
TEXT Operator instruction, e.g. “Min pressure allowed 785 mbar”
24
PAUSE WAIT, (for operator input to touch single step)
25
VENT Vent
END Program end
