PACE Pressure Controller User Manual
[EN] English 6 - 43 K0443 Revision A
6.14 Vacuum System Parts
The parts list below lists a typical system to supply vacuum, enabling the control of sub-
atmospheric pressures by the PACE instrument. Part numbers quoted in the table are taken
from the BOC Edwards Vacuum Products Catalogue. For more information, go to:
www.bocedwards.com.
Description Part Number Quantity
RV5 115/230Vac Vacuum Pump, 91 litre/min
A653-01-903 1
EMF10 Mist Filter
A462-26-000 1
NW25/NW10 Reducer fitting
C105-14-436 2
NW10 T-Piece Fitting
C105-11-411 1
IPVA10EK Air Admittance Valve, Normally Open
C417-21-000 1
NW10 Flexible Pipeline 1m, S/S
C105-11-287 4
NW10 Clamping Ring
C105-12-401 5
NW10 Centering Ring
C105-11-398 5
NW25 Clamping Ring
C105-14-401 3
NW25 Centering Ring
C105-14-398 3
NW16/10 Centering Ring
C105-12-349 1
NW16 to ¼NPT Male Adapter, S/S
C105-01-103 1
FL20K Foreline Trap
FL-20-K 1
