45
6. Remove the (2) screws holding the housing to the
console panel.
7. Release the (2) tabs, one on each side, locking
the housing to the console mounting panel.
Removing the detergent cavity assembly:
1. Disconnect the washer from the electrical supply,
remove the drawer and the top panel.
2. Disconnect the water valve assembly and the
overflow/vent tube and slide them back.
3. Release the wiring harness from the side of the
housing.
4. Disconnect the detergent dispenser outlet hose.
5. Remove the (2) screws holding the housing to the
center bar.
