53
Removing the tub assembly:
1. Disconnect the washer from the electrical supply
and the hot and cold water hoses.
2. Remove the top panel, console, front and rear
access panels and the front panel.
3. Disconnect the hose from the bellows, the deter-
gent outlet and siphon break hoses from the outer
tub.
4. Remove the drain pump and disconnect the drain
sump from the tub.
5. If you are going to replace the front half of the outer
tub remove the bellows and the weight ring.
6. Remove the small hose from the air bell.
7. Remove the large pulley, drive motor and speed
control board assembly.
8. Disconnect the bearing ground wire.
9. Remove the top pins from shock absorbers and push
the shock absorbers against the cabinet.
10. Place something down to protect the floor and
carefully turn the washer on it’s face to release the
springs.
11. Lift the cabinet off the tub.
