CONTROLS
54
Switches
Float Button
WARNING
Make sure the bucket is lowered to
the ground before putting the lift arms
in the Float mode. Putting the lift arms
in the Float mode while they are raised
will cause the bucket to fall and is
extremely dangerous.
Do not drive the loader forward with
the lift arms in the Float mode.
This button sets the lift arms to the Float
mode. The lift arms are put to the Float
mode while this button is pressed in. When
the button is released, the Float mode is
canceled.
Setting the arm float to the detent mode
To set to the detent mode, press and hold the
arm float button and move the right control
lever forward once. To turn off the detent
mode, move the right control lever rearward.
When in the Float mode, the bucket can
follow the contour of the ground without
movement of the control lever.
Ignition Switch
IMPORTANT: Do not repeatedly switch
the key from OFF to ON and ON to OFF
over a short period. Doing so will cause
engine breakdown.
PREHEAT ....... Position for preheating the
engine.
OFF ................ Position for stopping the
engine and inserting and
removing the key.
ON .................. Position in which the engine
is running. In this position, all
the electrical equipment is
functional.
START ............ Position for starting the engine.
When the key is released, the
switch automatically returns
to the ON position.
Horn Button
Press the right button on the right control
lever to blow the horn.
To Next Page
