TRANSPORT
96
WARNING
Know and use correct crane signals.
Inspect the hoisting equipment daily
for damaged or missing parts.
When hoisting, use a wire rope with
sufficient strength for the machine’s
weight.
Do not hoist with the machine in a
position other than the one described
in the procedure below. Doing so is
dangerous, because it may result in the
machine losing its balance.
Do not hoist the machine with an
operator on it.
When hoisting, hoist slowly so that the
machine does not tip.
Keep all other persons out of the
area when hoisting. Do not move
the machine over the heads of the
persons.
IMPORTANT: This hoisting method
applles to machines with standard
specifications.
The center-of-gravity differs according
to the attachments and options that are
mounted.
Consult a Gehl dealer.
Hoisting
1. Lower the bucket to the ground.
2. Raise the safety bar to engage the lock.
3. Stop the engine and remove the starter
key and get off the machine.
4. Install the sling as shown on the diagram.
Suspend in such a way that the sling and
lifting tool do not touch the chassis.
5. Hoist slowly until the machine just leaves
the ground.
6. Stop hoisting until the machine is stable
and hoist again slowly.
Hoisting position
< CTL55 / CTL65 >
< CTL75 / CTL85 >
