GEM-P9600 Programming Instructions
WI777D 08/00
!
Page 11
RF Transmitter Points
(Press the (
A
) button to set cursor.)
(For wireless systems only. Also see Quick Method, which follows)
For each transmitter (key fob transmitters also), enter the zone number
(01–96) to which the transmitter will be mapped, the 6-digit RF ID #:1-digit
checksum number printed on the transmitter and box, the point number
(1–4); enter “9” for unsupervised (all points). NOTE: When programming the
ID Code number, “A” =
G 0
; “B” =
G 1
; “C” =
G 2
; “D” =
G 3
; “E” =
G 4
;
“F” =
G 5. Press
J
to save. Press NEXT (E) button to proceed.
Quick Method. If a receiver is already installed in the panel, Napco
transmitter wireless points can be programmed automatically (“enrolled”)
using the following procedure. NOTE: The transmitter point will be enrolled
only if the signal strength is 3 or greater.
1. Enter the zone number to which the transmitter point will be mapped.
2. Press the
B
button to enter the Enroll Mode. The red and green LEDs
on the keypad will flash and the window will display as shown at left.
3. Open the loop of the point that is to be programmed (GEM-TRANS2 or
GEM-TRANS4 only).
4. Install the transmitter battery. The keypad will beep to indicate that the point has been successfully enrolled. Multi-point
transmitters can be mapped to successive zones simultaneously (Example 1) or to selected zones point by point
(Example 2).
Example 1. A 4-point transmitter has the RF ID number 410078:1. Map the first three points to Zones 11–13, respectively.
1. Enter the Enroll mode as described in step 2 above.
2. Enter Zone “11”.
3. Open the loops of points 1, 2 and 3.
4. Install the transmitter battery. The keypad will beep 3 times to indicate that three points have been programmed.
!
Transmitter 410078:1, point 1 will be mapped to Zone 11.
!
Transmitter 410078:1, point 2 will be mapped to Zone 12.
!
Transmitter 410078:1, point 3 will be mapped to Zone 13.
The keypad will now display Zone 13, the last zone enrolled.
Example 2. A 2-point transmitter has the RF ID number 287613:1. Map point 1 to Zone 6 and point 2 to Zone 9.
1. Enter the Enroll mode as described above.
2. Enter Zone “06”.
3. Open point-1 loop.
4. Install the battery. The keypad will beep once to indicate that one point has been programmed. (Transmitter 287613:1,
point 1 will be mapped to Zone 6.)
5. Enter Zone “09”.
6. Close point-1 loop and open point-2 loop.
7. Remove the transmitter battery, then re-install it. The keypad will beep once to indicate that one point has been
programmed. (Transmitter 287613:1, point 2 is mapped to Zone 9.)
Zone # Xmitter Check Point
Mapped to ID Sum #
ZN# XMIT#+CS P
ZN01-000000: 0- 0
ZN# XMIT#+CS P
ZN01-000000: 0- 0
ZN# XMIT#+CS P
ZN01-ENROLL:A--
KEY FOB ZONE ASSIGNMENT:
Key fobs can also be assigned to zones to allow multiple wireless panic buttons on one
alarm system, each reporting to a central station, a pager or having a description on the keypad that describes the person
holding the key fob, the location where the person holding the key fob is stationed, or the special purpose of the key fob
button being depressed. See the next page on Key fob Zone Assignment.
GEM-RP1CAe2 Keypad: RF Transmitter Points
To Next Page
