GEM-P9600 Programming Instructions
WI777D 08/00
!
Page 7
Exit/Entry Zones
(Appears for New Panel Only)
Directly enter the zone numbers which are to be used as Exit/Entry zones.
Valid entries are from 01 to 96. Directly enter each zone number, including
leading zeros. Use number buttons
1 through 9. NOTE: Press the
0
button for a zero. Press
J
to save and then repeat for any additional
zone(s). Press NEXT (
E) button to proceed.
NOTE:
Exit/Entry Zones will have an entry delay of 30 seconds and an exit delay of 60 seconds. Chime will automatically
be programmed for all E/E zones. If you are programming a 2 Area system, enter all of the zones required for Areas 1 & 2.
Interior Zones
(Appears for New Panel Only)
Directly enter the zone numbers which are to be used as Interior Zones. Valid
entries are from 01 to 96. Directly enter each zone number, including leading
zeros. Use number buttons
1 through 9. NOTE: Press the 0
button for a zero. Press
J
to save and then repeat for any additional zone(s).
Press NEXT (
E) button to proceed.
NOTE:
All Interior zones will also be automatically programmed as “Exit/Entry Follower” zones. If you are programming a
2 Area system, enter all the zones required for Areas 1 & 2.
Number of Keypads in Area 1
Directly enter the total number of Keypads to be installed in Area 1. Valid
entries are from 01 to 15. Directly enter the number of keypads, including
leading zeros. Use number buttons
1 through 9. NOTE: Press the
0
button for a zero. Press
J
to save. Press NEXT (
E
) to proceed.
Number of Keypads in Area 2
Directly enter the total number of Keypads to be installed in Area 2. Valid
entries are from 01 to 15.
Central Station Receiver 1 Telephone Number
Using number buttons, enter telephone number of up to 16 digits including
prefix letters, if necessary, for receiver 1. Use number buttons
1
through
9
for digits 1–9; press the
G 0
button for a zero and
G
1
through
G 5
for letters B–F, respectively. NOTE: Pre-Dial
Delay = “D”; Dial-Tone Detection = “E”. Pressing the
0 button will produce a blank space (•). Press
J
to save. Press
NEXT (
E
) to proceed. NOTE: Central Station Receiver 2 and 3 Telephone Numbers can only be entered in Direct
Address Programming. See CS Receiver Options.
(Direct Entry)
EXIT/ENTRY ZONES
ENTER ZONE # 00
(Direct Entry)
INTERIOR ZONES
ENTER ZONE # 00
(Direct Entry)
# AREA 1 KEYPADS
ENTER #KPS 01
(Direct Entry)
# AREA 2 KEYPADS
ENTER #KPS 00
(Direct Entry)
CENTRAL PHONE #
_____________
GEM-RP1CAe2 Keypad: Exit/Entry Zones, Interior Zones, Keypads per Area, CS Tel. No. & CS Acct. No.
Easy Programming of Auto download ID #'s and PC Preset Callback Numbers
(GEM-RP1CAe2 only)
For unattended PC Preset downloading, it is now possible to set the Auto download ID #’s and PC Preset Callback from
the Keypad Easy Program Mode.
• At the field for CENTRAL PHONE #, program an "F" followed by the Auto Download ID # (2 digits) and then the
Callback Telco # (up to 13 digits).
• Press [ON/OFF] to save.
• Exit Program Mode ([RESET] [RESET]).
•
Enter Master Code
• Press [FUNCTION]
• Go to Function "ACTIVATE DOWNLOAD Y/N" and press YES (INTERIOR).
• The panel will automatically call the PC Preset computer and download the program on the specified Auto
Download line # of PC Preset.
Example: Program an Auto download ID # of 07 and a PC Preset Callback #
of 1-516-842-9400
• Go to Central Phone # input screen and press: [*] [5] [0] [7] [1] [5] [1] [6] [8] [4] [2] [9] [4] [0] [0] [ON/OFF]
CENTRAL PHONE #
F0715168429400
