AREA OUTPUT CONTROL OPTIONS (ADDRESS 2700-2739)
AREA OUTPUT TURNS OFF UPON DISARM: Select options for any of the 5 Outputs per area when disarming a particular area.
!
1. Select the desired option by circling " the data values for left and right digits.
!
2. Add the data values (ex: 15=1+2+4+8) from the selected options.
!
3. Enter in right digit address location.
NOTE:
Dark shaded data value box shows option not available.
Area Output Control
[Default = 2700 (•1) 2708 (•1) ]
OUTPUT SILENCED
(TURNED OFF)
Burglary Output
Pulsed Burg. Output
Fire Output
Reset Relay
Auxiliary Relay
AREAS 5-8
LEFT DATA VALUES
(CIRCLE
"
)
A8 A7 A6 A5
8421
8421
8421
8421
8421
ADDRESS
2700-2732
LADDRR
2700
2708
2716
2724
2732
AREAS 1-4
RIGHT DATA VALUES
(CIRCLE
"
)
A4 A3 A2 A1
8421
8421
8421
8421
8421
DISARMING AREA 1 TURNS OFF AREA OUTPUT
AREAS 5-8
LEFT DATA VALUES
(CIRCLE
"
)
A8 A7 A6 A5
8421
8421
8421
8421
8421
ADDRESS
2701-2733
LADDRR
2701
2709
2717
2725
2733
AREAS 1-4
RIGHT DATA VALUES
(CIRCLE
"
)
A4 A3 A2 A1
8421
8421
8421
8421
8421
DISARMING AREA 2 TURNS OFF AREA OUTPUT
[Default = blank (•) blank (•) from address 2702-2735]
OUTPUT SILENCED
(TURNED OFF)
Burglary Output
Pulsed Burg. Output
Fire Output
Reset Relay
Auxiliary Relay
AREAS 5-8
LEFT DATA VALUES
(CIRCLE
"
)
A8 A7 A6 A5
8421
8421
8421
8421
8421
ADDRESS
2702-2734
LADDRR
2702
2710
2718
2726
2734
AREAS 1-4
RIGHT DATA VALUES
(CIRCLE
"
)
A4 A3 A2 A1
8421
8421
8421
8421
8421
DISARMING AREA 3 TURNS OFF AREA OUTPUT
AREAS 5-8
LEFT DATA VALUES
(CIRCLE
"
)
A8 A7 A6 A5
8421
8421
8421
8421
8421
ADDRESS
2703-2735
LADDRR
2703
2711
2719
2727
2735
AREAS 1-4
RIGHT DATA VALUES
(CIRCLE
"
)
A4 A3 A2 A1
8421
8421
8421
8421
8421
DISARMING AREA 4 TURNS OFF AREA OUTPUT
[Default = blank (•) blank (•) from address 2704-2737]
OUTPUT SILENCED
(TURNED OFF)
Burglary Output
Pulsed Burg. Output
Fire Output
Reset Relay
Auxiliary Relay
AREAS 5-8
LEFT DATA VALUES
(CIRCLE
"
)
A8 A7 A6 A5
8421
8421
8421
8421
8421
ADDRESS
2704-2736
LADDRR
2704
2712
2720
2728
2736
AREAS 1-4
RIGHT DATA VALUES
(CIRCLE
"
)
A4 A3 A2 A1
8421
8421
8421
8421
8421
DISARMING AREA 5 TURNS OFF AREA OUTPUT
AREAS 5-8
LEFT DATA VALUES
(CIRCLE
"
)
A8 A7 A6 A5
8421
8421
8421
8421
8421
ADDRESS
2705-2737
LADDRR
2705
2713
2721
2729
2737
AREAS 1-4
RIGHT DATA VALUES
(CIRCLE
"
)
A4 A3 A2 A1
8421
8421
8421
8421
8421
DISARMING AREA 6 TURNS OFF AREA OUTPUT
[Default = blank (•) blank (•) from address 2706-2739]
OUTPUT SILENCED
(TURNED OFF)
Burglary Output
Pulsed Burg. Output
Fire Output
Reset Relay
Auxiliary Relay
AREAS 5-8
LEFT DATA VALUES
(CIRCLE
"
)
A8 A7 A6 A5
8421
8421
8421
8421
8421
ADDRESS
2706-2738
LADDRR
2706
2714
2722
2730
2738
AREAS 1-4
RIGHT DATA VALUES
(CIRCLE
"
)
A4 A3 A2 A1
8421
8421
8421
8421
8421
DISARMING AREA 7 TURNS OFF AREA OUTPUT
AREAS 5-8
LEFT DATA VALUES
(CIRCLE
"
)
A8 A7 A6 A5
8421
8421
8421
8421
8421
ADDRESS
2707-2739
LADDRR
2707
2715
2723
2731
2739
AREAS 1-4
RIGHT DATA VALUES
(CIRCLE
"
)
A4 A3 A2 A1
8421
8421
8421
8421
8421
DISARMING AREA 8 TURNS OFF AREA OUTPUT
