GEM-P9600 Programming Instructions
L
NAPCO Security Systems
WI777D 08/00
!
Page 60
EZM GROUP OPTIONS (ADDRESS 2600-2621)
Default depends on Easy Menu Question “
# OF ZNS
IN AREA1
” and “
# OF ZNS IN AREA2
”. For example, If 96
zones are used, then all 22 groups will be
automatically enabled. If only 8 zones are used,
then groups 1-22 will be automatically disabled.
ADDRESS 2600
LEFT RIGHT
blank
(•)
EZM Group 1
ZONES 9-12
ADDRESS 2601
LEFT RIGHT
blank
(•)
EZM Group 2
ZONES 13-16
ADDRESS 2602
LEFT RIGHT
blank
(•)
EZM Group 3
ZONES 17-20
ADDRESS 2603
LEFT RIGHT
blank
(•)
EZM Group 4
ZONES 21-24
ADDRESS 2604
LEFT RIGHT
blank
(•)
EZM Group 5
ZONES 25-28
ADDRESS 2605
LEFT RIGHT
blank
(•)
EZM Group 6
ZONES 29-32
NOTE:
Zones 1-8 are included in the control panel and Zones 9-96 (Groups 1-22) are EZM Zones (either Wireless or Hardwired).
DATA
ENTRIES
RIGHT
blank (•)
1
OPTION
Not used
(No EZM
present)
4-Zone
EZM
EZM TYPE
EZM GROUP OPTIONS:
Up to 22 Groups of 4 Zones each may be programmed depending on the number of
zones used and which EZM modules are connected. Each group represents 4 zones.
!
1. Select EZM type from the table shown.
!
2. Enter in corresponding address locations above (right digit only).
NOTE:
Dark shaded data value box shows option not available.
[Default = blank (•) blank (•) from address 2622-2643]
EZM PGM ARMED TERMINAL CONTROL: For each zone group select the area(s) which, when armed, will activate the PGM Lug on
the corresponding EZM modules. Each zone group corresponds to 4 zones. If 8-Zone EZMs are used each one is treated as TWO zone
groups.
NOTE:
Lug goes ACTIVE (low) when ANY selected area is armed. When activated, the PGM Lug goes negative (to Ground).
!
1. Select the desired group number.
!
2. Enable desired options for each area by drawing a circle " around its corresponding binary data value.
NOTE:
No circle = feature disabled.
!
3. Enter data in corresponding left and right digit address locations above.
ADDRESS 2606
LEFT RIGHT
blank
(•)
EZM Group 7
ZONES 33-36
ADDRESS 2607
LEFT RIGHT
blank
(•)
EZM Group 8
ZONES 37-40
ADDRESS 2608
LEFT RIGHT
blank
(•)
EZM Group 9
ZONES 41-44
ADDRESS 2609
LEFT RIGHT
blank
(•)
EZM Group 10
ZONES 45-48
ADDRESS 2610
LEFT RIGHT
blank
(•)
EZM Group 11
ZONES 49-52
ADDRESS 2611
LEFT RIGHT
blank
(•)
EZM Group 12
ZONES 53-56
ADDRESS 2612
LEFT RIGHT
blank
(•)
EZM Group 13
ZONES 57-60
ADDRESS 2613
LEFT RIGHT
blank
(•)
EZM Group 14
ZONES 61-64
ADDRESS 2614
LEFT RIGHT
blank
(•)
EZM Group 15
ZONES 64-68
ADDRESS 2615
LEFT RIGHT
blank
(•)
EZM Group 16
ZONES 69-72
ADDRESS 2616
LEFT RIGHT
blank
(•)
EZM Group 17
ZONES 73-76
ADDRESS 2617
LEFT RIGHT
blank
(•)
EZM Group 18
ZONES 77-80
ADDRESS 2618
LEFT RIGHT
blank
(•)
EZM Group 19
ZONES 81-84
ADDRESS 2619
LEFT RIGHT
blank
(•)
EZM Group 20
ZONES 85-88
ADDRESS 2620
LEFT RIGHT
blank
(•)
EZM Group 21
ZONES 89-92
ADDRESS 2621
LEFT RIGHT
blank
(•)
EZM Group 22
ZONES 93-96
GROUP
NO.
1
2
3
4
5
6
7
8
9
10
11
AREAS 5-8
LEFT DATA VALUES
(CIRCLE
"
)
A8 A7 A6 A5
8421
8421
8421
8421
8421
8421
8421
8421
8421
8421
8421
ADDRESS
2622-2632
LADDRR
2622
2623
2624
2625
2626
2627
2628
2629
2630
2631
2632
AREAS 1-4
RIGHT DATA VALUES
(CIRCLE
"
)
A4 A3 A2 A1
8421
8421
8421
8421
8421
8421
8421
8421
8421
8421
8421
EZM PGM TERMINAL CONTROL
GROUP
NO.
12
13
14
15
16
17
18
19
20
21
22
AREAS 5-8
LEFT DATA VALUES
(CIRCLE
"
)
A8 A7 A6 A5
8421
8421
8421
8421
8421
8421
8421
8421
8421
8421
8421
ADDRESS
2633-2643
LADDRR
2633
2634
2635
2636
2637
2638
2639
2640
2641
2642
2643
AREAS 1-4
RIGHT DATA VALUES
(CIRCLE
"
)
A4 A3 A2 A1
8421
8421
8421
8421
8421
8421
8421
8421
8421
8421
8421
EZM PGM TERMINAL CONTROL
EZM Group Options
To Next Page
