GEM-P9600 Programming Instructions
WI777D 08/00
!
Page 33
Direct Address Programming Example
Example: Program Zones 6, 7 and 8 as Exit/Entry Follower Zones.
DETERMINE THE DATA ENTRIES
!
1. Referring to ZONE FEATURES in the Programming Worksheets that follow, Exit/Entry Follower for Zones 5
through 8 are located at address 1218, left digit. Circle
"
the data values for Zones 5–8.
!
2. Add the data values for Zones 6, 7 and 8: 2+4+8=14. From Tables 1 and 2, “14” (E) is entered as press
G4
. The right digit (for Zones 1 through 4, none of which are Exit/Entry Follower Zones) is entered as a
blank (•).
PROGRAM THE DATA ENTRIES
!
1. Enter the panel's Dealer Security Code (Address 0500), then press the A button.
!
2. Answer NO (F) to all questions until “
ACTIVATE PROGRAM Y/N
” is displayed; then press YES (E).
NOTE:
If you pass “
ACTIVATE PROGRAM
”, scroll backward using the the
B button.
!
3. Press the
C
button to enter the Address Program Mode. Address "
0000
" will display.
!
4. Press 1 2 1 8 to access Address 1218. The data for both digits will display and the cursor
will advance to the data field.
!
5. Press
G 4
to enter an “E” in the left digit and press
0
to enter a blank (•) in the right digit.
!
6. Press
J
to save.
ZONE OPTION
EXIT/ENTRY FOLLOWER
ZONES
LEFT DATA VALUES
SUM = 14 (CIRCLE
"
)
ZN08 ZN07 ZN06 ZN05
$#"
1
ADDRESS
1218
LADDR R
E 1218 blank (•)
ZONES
RIGHT DATA VALUES
SUM = 0 (CIRCLE
"
)
ZN04 ZN03 ZN02 ZN01
842
1
ENTER DATA
"
Direct Address Program Mode: Programming Example
