ASR-2000 Programming Manual
94
[:SOURce]:SIMulation:NORMal 1:VOLTage ... 104
[:SOURce]:SIMulation:REPeat:COUNt ............ 105
[:SOURce]:SIMulation:REPeat:ENABle ............ 105
[:SOURce]:SIMulation:TRANsition<1|2>:TIME
............................................................................... 106
[:SOURce]:SIMulation:TRANsition<1|2>:CODE
............................................................................... 106
:TRIGger:SIMulation:SELected:EXECute ......... 107
[:SOURce]:SIMulation:ABNormal:CODE
Set
Query
Description
Sets the external trigger output for the abnormal
step parameter. This option is only applicable
when in the Simulation mode.
Syntax
[:SOURce]:SIMulation:ABNormal:CODE
{<NR1>|MINimum|MAXimum}
Query Syntax
[:SOURce]:SIMulation:ABNormal:CODE?
[MINimum|MAXimum]
Parameter/Return
parameter
<NR1>
External trigger output, 0=LL, 1=LH,
2=HL, 3=HH.
MINimum
0 (LL)
MAXimum
3 (HH)
Example
SIM:ABN:CODE 1
[:SOURce]:SIMulation:ABNormal
:FREQuency
Set
Query
Description
Sets or queries the frequency of the abnormal step
of the simulation mode.
Syntax
[:SOURce]:SIMulation:ABNormal:FREQuency
{<NR2>|MINimum|MAXimum}
Query Syntax
[:SOURce]:SIMulation:ABNormal:FREQuency?
[MINimum|MAXimum]
Parameter/Return
parameter
<NR2>
Frequency of abnormal step
MINimum
Minimum frequency
MAXimum
Maximum frequency
