Setting the Output On Phase
Background
The on phase setting sets the starting phase of
the voltage output.
Steps
1. Press Shift + 7 to make the ON Phs
parameter selectable.
+
Also, it is available to use the scroll
wheel followed by the Enter key to
make the ON Phs parameter
selectable as well.
2. Set the ON Phs setting with the scroll wheel or
the numerical keypad or with the F3 (MAX) and
F4 (MIN) soft-keys to set the On Phase to the
maximum and minimum values, respectively.
AC+DC-INT, AC-INT, AC+DC-ADD,
AC-ADD, AC+DC-Sync, AC-Sync, AC-VCA
ON Phs
Range
0.0° ~ 359.9°
Soft-keys
FIXED/FREE, MAX, MIN
3. Press Enter to confirm the On Phase setting.
