2.3: FADERGLOW
GETTING STARTED > FADERGLOW
2.3: GETTING STARTED > FADERGLOW
Soundcraft FaderGlow™ is a unique feature that gives the user an additional level of status
indication,andcansignicantlyreduceoperatingerrors.
Several different functions can be assigned to the console faders, so it can be easy to lose track of which
function is currently being controlled, especially when grabbing a fader in a hurry. The main principle of
FaderGlow is to indicate the current fader function with colour, so more immediate recognition is possible.
SoundcraftFaderGlowisttedtoallconsolefadersthatcanchangetheirfunction.
The Si Impact FaderGlow colours are:
YELLOW: MIX 1-14 PRE-FADE bus master or contribution.
GREEN: MIX 1-14 POST FADE bus master or contribution
ORANGE: MATRIX master or matrix contribution.
CYAN: Stereo Input patched as an FX return or contribution.
MAGENTA: Stereo Input patched as a line source other than FX.
WHITE: Linked Mono Input Channel.
RED: GEQ (Graphic Equaliser).
BLUE: VCA Group Master.
