User Manual
7.2.5: ACS OUTPUT SECTION
DSP ELEMENTS > ACS > OUTPUT
7.2.4: DSP ELEMENTS > ACS > OUTPUT
The outputs section contains features
specictotheoutputsofallchannels.
Delay and Pan (or balance) are applicable
to all channel types, while LR and MONO/
CENTREroutingisspecictoinputand
Mix Bus Master output channels (not Matrix
master channels).
DELAY
Adjust the delay applied to this DSP Channel.
ACS units are milliseconds, though the Touch Screen will show feet and meters as well, with the Function Focus
feature.
PAN
Adjust the Pan (or balance for stereo channels) of the DSP Channel or Bus routing to the main
LR bus.
The Pan control operates as a channel-to-Left/Right, Mix Bus-to-Left/Right, or as a balance control when the
Left/Right Master Channel is selected.
