5.2: DEFAULT PATCHING

INPUTS AND OUTPUTS > DEFAULT PATCHING

5.2: INPUTS & OUTPUTS > DEFAULT PATCHING

The default patching for the Si Impact console - also shows default Fader Layers in brackets.

The console patching can be reset to default via the SYSTEM menu. VCA master assignments are

also shown for convenience, though there is no audio patching for these.

• XLR Mic/Line In 1-24 > Channels 1-24 (Fader Layer A, slots 1-24).

• XLR/Jack Combo Mic/Line In 25-32 > Channels 25-32 (Fader Layer B, slots 1-8).

• Unassigned inputs x 12 > Channels 33-44 (Fader Layer B, slots 9-20).

• Stereo FX Returns 1-4 > Stereo Input Channels 1-4 (Fader Layer B, slots 21-24).

• MIXES 1-14 > Analogue Line Out 1-14 (Fader Layer C slots 1-14).

• FX SEND MASTERS 1-4 > To Internal FX 1-4 (Fader Layer C slots 15-18).

• MTX 1-4 > Not Assigned (Fader Layer D slots 1-4).

• Main L&R > Analogue Line Out 15-16 (Master L&R Fader).

• MONO > Not Assigned (MONO/SEL Fader).

• VCA Group Masters 1-8 > (Fader Layer C slots 15-22)
