Video Security Control Panel User Manual
Chapter 5 Trouble Shooting
Q: What is the function of the Project button of LCD keypad?
A: Project button has button switch function besides normal instruction button, such as:
When sensor or module is abnormal, press and hold the Project button to switch to other interfaces
manually. When the sensor/module is abnormal or the keypad, press the Project button once and the
current display interface will be paused for 20s; press it again to switch to the next LCD screen interface.
Q: How to manually switch to other abnormal interfaces when the LCD keypad displays sensor/module is
abnormal?
A:
1. Among the LCD keypad abnormal display interfaces, sensor alarm display interface, module abnormal
display interface are of first priority; the sensor abnormal interface is of second priority, sensor bypass
interface is of third priority.
2. If interfaces of different priority exist at same time, the system automatically displays the interface of
first priority.
3. The switch between interfaces of same priority: there are two ways to switch sensor alarm display
interface to sensor off-line display interface.
1) System auto-switch: The system will refresh automatically. If the current display interface is
accomplished and other interfaces of same priority exist, system will auto switch to other
interfaces.
2) Manually switch: Press the Project button continuously until it switches to the interface to
display.
4. Switch between interfaces of different priority: from sensor alarm interface to sensor bypass interface:
Press and hold the Project button for multiple times until it switches to the interface to display.
Q: What is the meaning of LCD keypad Arm/Disarm, Operate indicators?
A: LCD system keypad indicator:
1. The meaning of Arm/Disarm indicator (Red and Green) is shown below:
Parameters Initialization
2. The meaning of Operate indicator (Green) is shown below:
