HIKVISION DS-19S08N-04F/K Series User Manual

Video Security Control Panel User Manual
--143-
-
Appendix1：Specifications
The specification of DS-19S08N-04F/Kx (Gx) video security control panel.
Model
DS-19S08N-04F/Kx
DS-19S08N-04F/KxGx
Security
Control
Panel
Parameters
Alarm Input
8-zone Alarm Input
Alarm Output
1-ch Local +8-ch expandable, 30VDC/1A
Siren Power Supply
12VDC /500mA
Keypad
K1: LED Keypad; K2: LCD Keypad
Supported External
Keypads
8
Tamper-proof Switch
Support Tamper-proof and Movement Prevention Function
Partition System
8 Partition Systems, 1 Public Partition System
Scheduled
Arming/Disarming
8 Time Periods Each Day
Detector Tamper-proof
Alarm
Support
Mobile APP
Support iOS, Alarm Push, Remote Arming/Disarming Function
Supported Remote
Controllers
32 (Unobstructed Effective Range of 100m)
SMS Alarm Data-push
N/A
Support
SMS
Arming/disarming
Data-push
N/A
Support
Media
Parameters
Network Video Input
4-ch HD Network Camera
Network Bandwidth
25Mbps
VGA Output Resolution
1-ch, Resolution: 1024×768/60Hz, 1280×720/60Hz, 1280×1024/60Hz,
1600×1200/60Hz, 1920×1080p/60Hz

HIKVISION DS-19S08N-04F/K Series Specifications

General

Model	DS-19S08N-04F/K Series
Category	Control Panel
Input Voltage	12 V DC
Operating Humidity	10% to 90% (non-condensing)
Material	Plastic
Operating Temperature	-10 °C to 55 °C (14 °F to 131 °F)
Installation	Wall Mounting
Compatibility	HIKVISION security systems

Summary

Safety Instruction

General Safety Warnings

Important safety precautions to prevent injury or property damage.

Chapter 1 Introduction

Chapter 2 Installation and Wiring

2.2 Wiring Device

Explains how to connect various devices and sensors to the control panel.

2.2.1 Wiring Detector

Guides on connecting alarm detectors to the input interfaces.

2.2.2 Wiring Alarm Output

Instructions for connecting alarm output devices like sirens.

2.2.3 Wiring Keypad

Details the connection procedure for keypads to the panel.

2.3.5 Activating the Control Panel

Step-by-step guide to activate the control panel using software.

Chapter 3 Keypad Operation (Local Operation)

3.1.1 Installer Password Settings

3.2 Keypad Alarm Operation Code

Commands for performing essential keypad operations.

3.2.1 Device Initialization

Restores the control panel to its default settings.

3.2.2 Security control panel Arming and Disarm

Procedures for arming and disarming the security system via keypad.

3.2.3 Stay Arming

3.2.4 Zone Bypass/Recovery

3.2.9 Emergency Alarm

Chapter 4 Accessing by Client Software

4.1 Installing the iVMS-4200

Guide for installing the client software for remote access.

4.2 User Registration and Login

4.3 Video Security Control Panel Settings

Configuring the control panel parameters via client software.

4.4 Remote Settings

Network Settings

Chapter 5 Trouble Shooting

Function of Project Button on LCD Keypad

Explains the function of the Project button on the LCD keypad.

Manually Switch Abnormal Interfaces

Steps of LED Keypad Programming

Notes for Setting Password

Notes for Setting Duress Code

Appendix1: Specifications
