HIKVISION DS-7600NI-I2 Series User Manual

Network Video Recorder User Manual
119
Figure 11-8 Create Array
6. Enter Array Name.
7. Select RAID Level as required.
8. Select the physical disks to constitute the array.
Table 11-1 The Required Number of HDDs
RAID Level
The Required Number of HDDs
RAID 0
At least 2 HDDs.
RAID 1
At least 2 HDDs.
RAID 5
At least 3 HDDs.
RAID 6
At least 4 HDDs.
RAID 10
The number of HDD must be an even ranges from 4 to 16.
9. Click OK.
10. Optional: The video recorder will automatically initialize the created array. Go to Storage →
RAID Setup → Array to view the information of the created array.
Figure 11-9 Array List
