Network Video Recorder User Manual
92
Frame Rate (FPS - Frames Per Second): refers to how many frames are captured each second. A
higher frame rate is advantageous when there is movement in the video stream, as it maintains
image quality throughout.
Resolution: Image resolution is a measure of how much detail a digital image can hold: the
greater the resolution, the greater the level of detail. Resolution can be specified as the number
of pixel-columns (width) by the number of pixel-rows (height), e.g.,1024×768.
Bitrate: The bit rate (in kbit/s or Mbit/s) is often referred to as speed, but actually defines the
number of bits/time unit and not distance/time unit.
Enable H.264+ Mode: The H.264+ mode helps to ensure the high video quality with a lowered
bitrate. It can effectively reduce the need of bandwidth and HDD storage space.
A higher resolution, frame rate and bitrate setting will provide you the better video quality, but
it will also require more internet bandwidth and use more storage space on the hard disk drive.
Sub-Stream
The sub-stream is a second codec that runs alongside the mainstream. It allows you to reduce the
outgoing internet bandwidth without sacrificing your direct recording quality.
The sub-stream is often exclusively used by smartphone applications to view live video. Users with
limited internet speeds may benefit most from this setting.
The picture refers to the live picture capture in continuous or event recording type.
Picture Quality: set the picture quality to low, medium or high. The higher picture quality
results in more storage space requirement.
Interval: the interval of capturing live picture.
Configure Advanced Recording Settings
Go to Storage > Record Schedule.
Check Enable Schedule to enable scheduled recording.
Click Advanced to set the recording parameters.
