HIKVISION DS-K1TA70MI-T User Manual

The wiring diagram without secure door control unit is as follows.
Figure 4-2 Device Wiring
Note
• You should set the face
recognion terminal's Wiegand direcon to "Input" to connect to a
Wiegand card reader. If connects to an access controller, you should set the Wiegand direcon to
"Output" to transmit authencaon informaon to the access controller.
• For details about Wiegand direcon sengs, see Seng Wiegand Parameters in Communicaon
Sengs
.
• The power supply for the device should be 12 VDC/2 A. The suggested external power supply for
door lock is 12 V, 1 A. The suggested external power supply for the Wiegand card reader is 12 V,
1A.
• The suggested power cable's diameter: 22 AWG. The suggested other cable's diameter: 26 AWG.
• Do not wire the device to the electric supply directly.
Warning
The face recognion terminal shall adapt an external listed Class 2 power supply with surge
protected funcon.
Face Recognion Terminal User Manual
13
