10-34 Vehicle Care
F52 BRAKE
VACUUM PUMP
30A
F53 AIR
CONDITIONING
CLUTCH
10A
F54 VAPORISER
CONTROL
MODULE
10A
Relays
R1 DRIVING LAMPS
R2 HEADLAMP WASHER
R3 REAR WASHER PUMP
R4 FRONT WASHER PUMP
R5 REAR DEMISTER
R6 FRONT WIPER CONTROL
R7 WIPER SPEED
R8 ENGINE CONTROL
MODULE
R9 -
R10 INCLR PUMP
R11 -
R12 REAR WIPER CONTROL
R13 FOG LAMPS
R14 LOW BEAM HEADLAMPS
R15 HIGH BEAM HEADLAMPS
R16 STARTER
R17 RUN / CRANK
R18 BRAKE VACUUM PUMP
R19 AIR-CONDITIONING
CONTROL
R20 HORN
Note: Relays R3, R4, R12,
R13 and R20 are PCB mounted
relays.
Vehicle Tools
Tools
The jack and tools are located
behind the driver seat.
Headlamp tool
The vehicle may have a torx tool for
use when replacing the front
headlamp bulbs. See Bulb
Replacement on page 10-17.
