FUEL SYSTEM
FUEL FILLER CAP REMOVAL/
INSTALLATION
Turn the fuel level gauge (1) to align the fuel filler cap
tether hole (2) with the cutout (3) of the fuel filler neck, and
then remove the fuel filler cap (4).
Before installing, check the air vent hole of the fuel filler
cap for clogs. If necessary, clean it using low-pressure
compressed air.
Set the fuel tank cap to the fuel filler neck by aligning the
projections (5) of the cap with the cutouts of the fuel filler
neck and fuel level gauge, and then turn the fuel tank cap
clockwise 180 degrees to lock it.
FUEL FILTER REMOVAL/
INSTALLATION
Remove or install the fuel filter by aligning the cutout (1) of
the fuel filter with the fuel filler cap tether (2) as shown.
Before installing, check the screen of the fuel strainer for
clogs or damage.
(2)
(3)
(5)
(1)
(4)
(2)
(1)
