Instruments & Controls
15
Operation Component Locations
start/override button
ignition
switch
headlight switch
differential lock switchheadlight
dimmer switch
throttle lever
rear brake lever/
parking brake lever
gearshift
switches
range select lever
horn button
front brake
lever
4WD switch
engine stop switch
P/R lever
drive mode select switch
19 TRX500FA6 (ED)-32HR66400.book 15 ページ ２０１８年５月２２日　火曜日　午前１１時８分
