Instruments & Controls
59
Controls & Features
The utility box (1) is located on the left side of the front fender. You
may store small, lightweight items in the box.
To open:
Pull up the front of the utility box cover (2).
To close:
Push down the front of the utility box cover until it locks in place.
Make sure that the stud (3) is locked securely in position by pulling
up lightly on the front of the utility box cover.
Utility Box
LEFT FRONT FENDER
(3)
(1) utility box
(2)
(1)
(2) utility box cover
(3) stud
19 TRX500FA6 (ED)-32HR66400.book 59 ページ ２０１８年５月２２日 火曜日 午前１１時８分
