11 - 7
Output Selections
Image VGA Off
IMGVGA0
4-1
*On
IMGVGA1
4-1
Beeper - Good Read Off
BEPBEP0
4-2
*On
BEPBEP1
4-1
Beeper Volume -
Good Read
Off
BEPLVL0
4-1
Low
BEPLVL1
4-2
*Medium (default for
5X10)
BEPLVL2
4-2
*High (default for 5X80)
BEPLVL3
4-2
Beeper Pitch - Good
Read (Frequency)
Low (1600) (min 400Hz)
BEPFQ11600
4-2
*Medium (3250)
BEPFQ13250
4-2
High (4200) (max
9000Hz)
BEPFQ14200
4-2
Beeper Duration -
Good Read
*Normal Beep
BEPBIP0
4-3
Short Beep
BEPBIP1
4-3
LED - Good Read Off
BEPLED0
4-3
*On
BEPLED1
4-3
LED Good Read
Polarity
Active High
GRDINV1
4-5
*Active Low
GRDINV0
4-4
Number of Beeps -
Good Read
Range 1 - 9
BEPRPT#
4-4
*1
BEPRPT1
4-4
Beep Polarity Active High
BEPINV1
4-5
*Active Low
BEPINV0
4-5
User-Specified Good
Read Delay
Range 0 - 30,000 ms
DLYGRD#####
4-6
Good Read Delay *No Delay
DLYGRD0
4-5
Short Delay (500 ms)
DLYGRD500
4-5
Medium Delay (1000 ms)
DLYGRD1000
4-5
Long Delay (1500 ms)
DLYGRD1500
4-5
Selection
Setting
* Indicates default
Serial
Command
# Indicates a
numeric entry
Page
