7 - 20
Code 128 Message Length
Scan the bar codes below to change the message length. Refer to Message
Length Description (page 7-2) for additional information. Minimum and
Maximum lengths = 0-80. Minimum Default = 0, Maximum Default = 80.
Code 128 Code Page
Code pages define the mapping of character codes to characters. If the data
received does not display with the proper characters, it may be because the bar
code being scanned was created using a code page that is different from the
one the host program is expecting. If this is the case, scan the bar code below,
select the code page with which the bar codes were created (see Code Page
Mapping of Printed Bar Codes on page A-5), and scan the value and the Save
bar code from the Programming Chart on the inside the back cover of this
manual. The data characters should then appear properly.
Default = 2.
Telepen
<Default All Telepen Settings>
Minimum Message Length
Maximum Message Length
To Next Page
