UDACT Instruction Manual — P/N 50050:M 12/18/2009 31
Programming Options Programming Instructions
3.4.2 Primary Number Account Code (17-20)
Four locations at addresses 17-20 default to all “0”s. Valid entries are (0-9 and A-F). The number of
digits entered must match the format selection. If programming “2” or “4” into address 16, enter 3
digits (location 20 is ignored). If programming “0”, “1”, “6”, “8”, “A”, “C”, or “E” into address 16,
enter 4 digits.
3.4.3 Primary Number 24 Hour Test Time (21-24)
Use military time when entering the 24 hour Test Time. The 24 hour test report to phone number 1
takes up four locations, from addresses 21-24. The default is 00:00 (12:00 midnight). The limits for
each location are as follows; 21: enter 0, 1 or 2; 22: enter 0-9; 23: enter 0-5; 24: enter 0-9.
3.4.4 Primary Number 24/12 Hour Test Time Interval (25)
The test report sent to the primary phone number may be sent every 12 or 24 hours. If the message
is to be sent every 24 hours, leave the factory default entry of zero. If 12 hour test report time is
needed, enter 1.
3.4.5 Secondary Phone Number (26-41)
Programming is similar to programming the primary phone number located at addresses 00 - 15.
The defaults are also all “F”s.:
3.4.6 Secondary Number Communication Format (42)
Programming is the same as the primary number's Communication Format at address 16. Default
entry is “E”, Contact ID. When selecting the format, note that Ademco Contact ID is the only
format in the UDACT which identifies the specific zone or point status to the Central Station. All
other formats report the number of zones or points that are active but do not identify the specific
zone or point. Choose one entry from the list below:
NOTE: Do not use A-F.
FFFFFFFFFFFFFFFF
26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41
0: 4+1 Ademco Express Standard, DTMF, 1400/2300 ACK
1: 4+2 Ademco Express Standard, DTMF, 1400/2300 ACK
2: 3+1 Standard 1800 Hz Carrier, 2300 Hz ACK
3: Not Used
4: 3+1 Standard 1900 Hz Carrier, 1400 Hz ACK
5: Not Used
6; 4+1 Standard 1800 Hz Carrier, 2300 Hz ACK
7: Not Used
