UDACT Instruction Manual — P/N 50050:M 12/18/2009 83
Event Code/Report Transmission AFP-300 & AFP-400 (UL 8th)
E.5 Event Code/Report Transmission
Via Ademco Contact ID Format Only
E.5.1 For Zone Reporting:
Zones 1 - 99 report as zone numbers 01 - 99
E.5.2 For Point Reporting:
Loop 1, Modules 101 - 196 report as device numbers 01 - 96 (Report defaults to '110')
Loop 2, Modules 201 - 296 report as device numbers 101 - 196 (Report defaults to '110')
Loop 1, Detectors 101 - 196 report as device numbers 201 - 296 (Report defaults to '111')
Loop 2, Detectors 201 - 296 report as device numbers 301 - 396 (Report defaults to '111')
Output Modules 1 - 64 report as device numbers 401 - 464 (Report defaults to '380', trouble only)
Following are module locations and their corresponding addresses in various cabinets:
CAB - B3
CAB - C3
CAB - 400AA
!
CAUTION: Point reports for Loop 1, Modules 197 through 199, Detectors 197 through 199 and
point reports for Loop 2, Modules 297 through 299 and Detectors 297 through 299 are omitted.
However, when devices are installed on either SLC and the device is in alarm or trouble, the
UDACT will transmit the general alarm and general trouble reports if enabled.
AFP-300/400 CPU 417-424 425-432
433-440 441-448 449-456 457-464
AFP-300/400 CPU
401-408 409-416 417-424 425-432
433-440 441-448 449-456 457-464
AFP-300/400 CPU 401-408
NOTE: In order for point reporting of System 5000 modules to report as shown above, be certain
to use the last connectors on the module slot cable.
