56 UDACT Instruction Manual — P/N 50050:M 12/18/2009
Section 5: Reporting Formats
5.1 Data Reporting Structure
The table below shows the data reporting structure for each of the pulsed formats as well as the
Ademco Express formats.
• Ademco Express formats allow a typical data message to be transmitted to the Central
Station in under 5 seconds.
• Pulsed formats typically require 15 to 20 seconds in comparison.
Table 5.2 on page 57 defines each letter code used in Table 5.1.
Table 5.3 on page 58 describes the data reporting structure used for Ademco Contact ID format.
Do not select any of the pulsed or Ademco Express Formats if identification of the specific zone or
point is desired. Use Ademco Contact ID for specific zone or point identification.
Table 5.1 Data Reporting Structure
Format #
0, 2, 4, 6, 8
Format #
1, A, C
Report 3+1/4+1/Standard
4+1 Express
4+2/Standard
4+2 Express
Alarm SSS(S) A SSSS AA2
Alarm Restore SSS(S) RA SSSS RARA2
Zone Trouble
(Zone Open)
SSS(S) RTZ SSSS TZTZ2
Zone Trouble Restore SSS(S) RTZ SSSS RTZRTZ2
System Trouble SSS(S) TS SSSS TSTS2
System Trouble Restore SSS(S) RTS SSSS RTSRTS2
Low Battery SSS(S) L SSSS LL2
Low Battery Restore SSS(S) RL SSSS RLRL2
AC Loss SSS(S) P SSSS PP2
AC Loss Restore SSS(S) RP SSSS RPRP2
Supervisory Condition SSS(S) V SSSS VV2
Supervisory Condition Restore SSS(S) RV SSSS RVRV2
Test Report SSS(S) X SSSS XX2
Abnormal Test Report SSS(S) XA SSSS XAXA2
NOTE: Refer to Table 6 on page 61 for a list of compatible receivers.
