32 UDACT Instruction Manual — P/N 50050:M 12/18/2009
Programming Instructions Programming Options
3.4.7 Secondary Number Account Code (43-46)
This code is programmed in addresses 43 - 46 in the same manner as the primary phone number
Account Code. Default entries are all “0”s.
3.4.8 Secondary Number 24-Hour Test Time (47-50)
This number is programmed in addresses 47-50 in the same manner as the primary number 24-
Hour Test Time. Default is 00:00 (12:00 midnight).
3.4.9 Secondary Number 24/12 Hour Test Time (51)
The test report sent to the Secondary phone number may be sent every 12 or 24 hours. If the report
is to be sent every 24 hours, leave the factory default entry of zero. If a 12 hour test report time is
needed, enter 1.
3.4.10 Start Monitoring Address (52-53)
This address is programmed to indicate the first group of zones or points to be monitored and
reported to the Central Station. See the table below.
3.4.11 End Monitoring Address (54-55)
This address is programmed to indicate the last group of zones or points to be monitored and
reported to the Central Station. See the table below. Use the Start and End Monitoring Address
programming locations to set the reporting range of the UDACT.
8: 4+1 Standard 1900 Hz Carrier, 1400 Hz ACK
9: Not Used
A: 4+2 Standard 1800 Hz Carrier, 2300 Hz ACK
B: Not Used
C: 4+2 Standard 1900 Hz Carrier, 1400 Hz ACK
D: Not Used
E: Ademco Contact ID (default)
F: Not Used
0: 4+1 Ademco Express Standard, DTMF, 1400/2300 ACK
!
CAUTION:Default entries for event codes are always programmed into memory when
ENTER/STORE is pressed at this location! This can be avoided by using the up or down arrows to
navigate through programming locations.
