58 UDACT Instruction Manual — P/N 50050:M 12/18/2009
Reporting Formats Data Reporting Structure
5.1.1 Ademco Contact ID
The reporting structure for the Ademco Contact ID format is as follows:
SSSS 18 QXYZ GG CCC
Table 5.3 Ademco Contact ID Reporting Structure
A typical printout of alarm and trouble reports in the Ademco Contact ID Reporting Structure
follows:
SSSS = Four digit Subscriber ID (addresses 17 - 20 and 43 - 46)
18 = Identifies transmission as Contact ID to the receiver at the
Central Station
Q = Event Qualifier; 1 = New Event, 2 = New Restore
XYZ = Event Code (shown in Table 3.2 to Table 3.7)
GG = Group or Loop number
CCC = Device or Zone number
NOTE: For general reports (alarm, trouble and supervisory), the GG and CCC fields are
transmitted as 00 and 000 unless changes to addresses 64-65 and 66-68 are made.
64 - 65 = Loop number (GG), (factory default is 00)
66 - 68 = Device/Zone number (CCC) for General Alarm, Fault or Supervisory messages (factory
default is 000).
Time Date
Rcvr/
Line ID
SSSS QXYX GG CCCC
11:28 10/14 11 7777 E110 00 C000 General Alarm
11:28 10/14 11 7777 E111 00 C046 Alarm SD46
11:28 10/14 11 7777 E300 00 C000 General Trouble
11:28 10/14 11 7777 E380 00 C046 Trouble SD46
11:28 10/14 11 7777 R110 00 C000 General Alarm Restore
11:28 10/14 11 7777 R111 00 C046 Alarm SD46 Restore
11:28 10/14 11 7777 R300 00 C000 General Trouble Restore
11:28 10/14 11 7777 R380 00 C046 Trouble SD46 Restore
NOTE: In the sample report, SD46 refers to smoke detector at address 46 or on zone 46.
18, which is used in the reporting structure to identify the transmission as Contact ID, is not
printed out in the alarm and trouble report.
Q, which is the Event Qualifier for the reporting structure, is printed out in the report as an E for
New Event or R for New Restore.
CCCC, the first C is not transmitted by the UDACT but is printed by the Central Station Receiver
printer output.
