106
• The HPE 3100 v2 EI switches support port-based VLAN, MAC-based VLAN, and
protocol-based VLAN.
• The HPE 3100 v2 SI switches support port-based VLAN and MAC-based VLAN.
• On a port configured with port-based VLAN, MAC-based VLAN, and protocol-based VLAN, the
switch determines which VLAN a packet that passes through the port should be assigned to by
looking up the VLANs in the default order of MAC-based VLAN, protocol-based VLAN, and
port-based VLAN.
Protocols and standards
IEEE 802.1Q, IEEE Standards for Local and Metropolitan Area Networks: Virtual Bridged Local Area
Networks
Configuring basic VLAN settings
Configuration restrictions and guidelines
• As the default VLAN, VLAN 1 cannot be created or removed.
• You cannot manually create or remove VLANs reserved for special purposes.
• To delete a protocol reserved VLAN, voice VLAN, management VLAN, dynamic VLAN, VLAN
with a QoS policy applied, control VLAN for a smart link group, control VLAN for an RRPP
domain, remote probe VLAN for remote port mirroring, remove the configuration from the VLAN
first, and execute the undo vlan command.
Configuration procedure
To configure basic VLAN settings:
Step Command Remarks
1. Enter system view.
system-view
N/A
2. Create a VLAN and
enter its view, or create
VLANs in batch.
vlan
{ vlan-id1 [
to
vlan-id2 ] |
all
}
Optional.
By default, only the default VLAN (VLAN
1) exists in the system.
3. Enter VLAN view.
vlan
vlan-id
Required only when you create VLANs in
bulk.
4. Configure a name for
the VLAN.
name
text
Optional.
By default, the name of a VLAN is its
VLAN ID (
VLAN 0001
, for example).
5. Configure a description
for the VLAN.
description
text
Optional.
The default description is VLAN vlan-id,
which is the ID of the VLAN. For example,
the description of VLAN 100 is
VLAN
0100
by default.
Configuring basic settings of a VLAN interface
You can use VLAN interfaces to provide Layer 3 communication between hosts of different VLANs.
VLAN interfaces are virtual interfaces used for Layer 3 communication between different VLANs.
