HP 54753A User Manual

Specifications and Characteristics
Environmental Specifications
12-5
Environmental Specifications
dc Offset Range
8
±
500 mV
Nominal Input Impedance 50 [ohm ]
Connectors 3.5mm (m), channel and trigger
Input Reflection/Return Loss
≤
5% for 30 ps rise time
Number of Channels 2
Dynamic Range/Maximum Specified Input Power
±
400 mV relative to channel offset
Maximum Safe Input
±
2V + peak ac (+16 dBm)
1
The input sampler is biased differently for increased bandwidth in the 18 GHz bandwidth mode.
2
For the HP 54753A channel 2 only
3
When operated within ±5°C (±9°F) of the temperature of the last plug-in calibration.
4
When driven from a 0 ohm source.
5
It is recommended that a user vertical calibration be performed after every 10 hours of continuous use or if
the temperature has changed by greater in 2°C from the previous vertical calibration.
6
When operated within ±2°C (±3.6°F) of the temperature of the last plug-in calibration. When operated within
±5°C (±9°F) of the temperature of the last plug-in calibration, the final term in the dc accuracy specification
is 2.5 times higher.
7
Where
∆
T
cal
represents the temperature change in Celsius from the last user vertical calibration.
8
An effective offset of ±900 mV can be achieved using the ±500 mV of channel offset and adding ±400 mV of
offset using the waveform math offset scaling function.
Temperature
Operating 15
°
C to +35
°
C
Non-operating
−
40
°
C to +70
°
C
Humidity
Operating up to 90% relative humidity at 35
°
C
Non-operating up to 90% relative humidity at 35
°
C
!
