Bezel Blanks
1. Prepare the computer for disassembly (Preparation for Disassembly on page 56).
2. Remove the access panel (
Access Panel on page 57).
3. Remove the front bezel (
Front Bezel on page 58).
5.25-inch Drive Bezel Blank
While facing the inside of the front bezel, press the two retaining tabs on the right toward the outer edge
of the bezel (1) and pull the bezel blank inward (2) to remove it.
To install a bezel blank, reverse the removal procedure.
Bezel Blanks 59
