Chapter 1
HP Integrity rx8640 and HP 9000 rp8440 Server Overview
Detailed Server Description
35
IMPORTANT Always refer to the PCI card’s manufacturer for the specific PCI card performance
specifications. PCI, PCI-X mode 1, and PCI-X mode 2 cards are supported at different clock
speeds. Select the appropriate PCI-X I/O slot for best performance.
Table 1-8 PCI-X Slot Types
I/O
Partition
Slot
a
a. Each slot will auto select the proper speed for the card installed up to the maximum speed for
the slot. Placing high speed cards into slow speed slots will cause the card to be driven at the
slow speed.
Maximum
MHz
Maximum
Peak
Bandwidth
Ropes
Supported
Cards
PCI Mode
Supported
0 8 133 533 MB/s 001 3.3 V PCI or PCI-X
Mode 1
7 133 1.06 GB/s 002/003 3.3 V PCI or PCI-X
Mode 1
6 266 2.13 GB/s 004/005 3.3 V or 1.5 V PCI-X Mode 2
5 266 2.13 GB/s 006/007 3.3 V or 1.5 V PCI-X Mode 2
4 266 2.13 GB/s 014/015 3.3 V or 1.5 V PCI-X Mode 2
3 266 2.13 GB/s 012/013 3.3 V or 1.5 V PCI-X Mode 2
2 133 1.06 GB/s 010/011 3.3 V PCI or PCI-X
Mode 1
1 133 1.06 GB/s 008/009 3.3 V PCI or PCI-X
Mode 1
1 8 133 533 MB/s 001 3.3 V PCI or PCI-X
Mode 1
7 133 1.06 GB/s 002/003 3.3 V PCI or PCI-X
Mode 1
6 266 2.13 GB/s 004/005 3.3 V or 1.5 V PCI-X Mode 2
5 266 2.13 GB/s 006/007 3.3 V or 1.5 V PCI-X Mode 2
4 266 2.13 GB/s 014/015 3.3 V or 1.5 V PCI-X Mode 2
3 266 2.13 GB/s 012/013 3.3 V or 1.5 V PCI-X Mode 2
2 133 1.06 GB/s 010/011 3.3 V PCI or PCI-X
Mode 1
1 133 1.06 GB/s 008/009 3.3 V PCI or PCI-X
Mode 1
