Chapter 2
Installing the System
Installing the Power Distribution Unit
59
Installing the Power Distribution Unit
The server may ship with a power distribution unit (PDU). Two 60 A PDUs available for the server. Each
PDU 3 U high and is mounted horizontally between the rear columns of the server cabinet. The 60 A PDUs
are delivered with an IEC-309 60 A plug.
The 60 A NEMA
1
PDU has four 20 A circuit breakers and is constructed for North American use. Each of the
four circuit breakers has two IEC
2
-320 C19 outlets providing a total of eight IEC-320 C19 outlets.
The 60A IEC PDU has four 16A circuit breakers and is constructed for International use. Each of the four
circuit breakers has two IEC-320 C19 outlets providing a total of eight IEC-320 C19 outlets.
Each PDU is 3U high and is rack-mounted in the server cabinet.
Documentation for installation will accompany the PDU. The documentation can also be found at the external
Rack Solutions Web site at:
http://www.hp.com/racksolutions
This PDU might be referred to as a Relocatable Power Tap outside HP.
The PDU installation kit contains the following:
• PDU with cord and plug
• Mounting hardware
• Installation instructions
1. NEMA: National Electrical Manufacturers Association
2. IEC: International Electrotechnical Commission
