Chapter 2
Installing the System
Installing the Top and Side Covers
57
Step 5. Place the cover in a safe location.
Figure 2-15 Top Cover Detail
Installing the Top Cover
The following section describes the procedure for installing the top cover.
Step 1. Orient the cover according to its position on the chassis.
Step 2. Slide the cover into position using a slow, firm pressure to properly seat the cover.
Step 3. Tighten the blue retaining screws securing the cover to the chassis.
Removing the Side Cover
The following section describes the procedure for removing the side cover.
Step 1. Connect to ground with a wrist strap.
Retaining Screws
To Next Page
